Customized GaN charger and power supply IP65

Customized GaN charger and power supply, 200W ~ 1000W, IP65,

Customized GaN charger and power supply IP65

Using GaN new technology, customized power adapter and battery chargers can reach very high effiency up to 97%~98%, so the power unit and charger will be more slim and smaller than traditional power s...

Specifications

Using GaN new technology, customized power adapter and battery chargers can reach very high effiency up to 97%~98%, so the power unit and charger will be more slim and smaller than traditional power supply products, only 30% or less. High power effiency means low heating generated. This means 200W ~ 1000W GaN power supply and charger can easily meet waterproof IP65 or IP67 requirement, because there the air fan can be removed.


Our main strengths:

1) The products  accordance with LVD & EMC standards, meet CCC, UL, CE, TUV, PSE, KC, RCM, BS.

2) Strict and standardized design/manufacture standards, high product quality and high reliability.

3) With over 25 years of SMPS experience engineers in hardware, software, and quality control.

4) Fast response speed and excellent product price performance help customers save time and cost

5) Full team with electronic circuit hardware, on-board software, application software and mechanical.


Using GaN new technology, customized power adapter and battery chargers can reach very high effiency up to 97%~98%, so the power unit and charger will be more slim and smaller than traditional power supply products, only 30% or less. High power effiency means low heating generated. This means 200W ~ 1000W GaN power supply and charger can easily meet waterproof IP65 or IP67 requirement, because there the air fan can be removed.


Our main strengths:

1) The products  accordance with LVD & EMC standards, meet CCC, UL, CE, TUV, PSE, KC, RCM, BS.

2) Strict and standardized design/manufacture standards, high product quality and high reliability.

3) With over 25 years of SMPS experience engineers in hardware, software, and quality control.

4) Fast response speed and excellent product price performance help customers save time and cost

5) Full team with electronic circuit hardware, on-board software, application software and mechanical.


The following is a sample for 480W daul channel fast charger for marine application





480W Dual Channel 27.6V 8A Charger marine charger

Rating Input: AC 100~240V

Power factor: >0.95

Power effiency: >96.7% @220V input, full load output

Rating Output: 2 * 27.6V 8A

Protections:  OCP, PLP, OVP, OTP, short circuits

IP Class: IP65

Output Feature:  standard 3 stages

Communication: none

LVD & EMC:  UL1012 + EN61000,  CE、cTUVus

Size & Weight: 120x 120 x 29mm/1Kg

Housing: Aluminum Alloy
