BM200-xx Battery Tester & Analyzer

BM200 is an intelligent instrument that integrates the four functions of battery testing(analyzing), charging, discharging and maintenance. It is designed with a portable plastic shell, and with color TFT displayer and silicon touch keys.

The BM200 is a powerful assistant for electronic engineers. It can be used to perform performance testing, capacity testing, characteristic curve measurement, and activation and maintenance of long-term storage batteries for various commonly used rechargeable batteries.

BM200 is widely used for performance testing and routine maintenance of most rechargeable batteries in many portable electronics/electrical devices (such as smart phone, tablet PC, drone, e-bike, e-scooter, power tool, car …). Battery voltage range is 2V ~ 29V capacity range 1Ah~300Ah, and battery types cover Li-ion /LiFePO4 /Pb-Acid /NiMH.

Input of BM200 is AC100~240V, universal global voltage range. The adjustable range of output constant current charging current is 3A~30A / 1A~10A ; The charging limit voltage and the discharge cut-off voltage can also be adjusted under 32V. It has a variety of abnormal safety protection measures such as battery reverse connection, wrong connection, short circuit, overvoltage, undervoltage, over-current and over-current heat.

BM200-BL has Bluetooth function, through which users can view the historical charging and discharging data and curves with their phones or PC.

BM200 is desged for many applications, like:

1) Capacity measurement, internal resistance, and health testing of power and energy storage batteries (lithium ion, iron lithium, lead-acid, etc.)

2) Recovery, activation, measurement, and maintenance of the effective capacity of storage batteries that have been idle for more than 6 months

3) Capacity, internal resistance, and health testing of single or combined batteries for electric bicycles, tricycles, and electric sightseeing vehicles

Specifications:

Input voltage: 100~240V 50HZ

Suitable batteries: Pb-Acid, Li-Ion, LiFePO4, NiMH, NiCD....

Analyzer: battery voltage, internal resistance, capacity, SOC, SOH, charging/discharge curves

Charging method:  smart charging process for different battery type.

Suitable capacity: 1Ah~300Ah

Voltage range:  BM200-05: 2V~5V;  BM200-32: 2V~32V

Charge current: BM200-05: 3~30A,  BM200-32: 1~10A

Discharge current: BM200-05: 0~20A,  BM200-32: 0~10A

Temperature compensation: Automatically compensating

Voltage accuracy: +- 1.5%

Current accuracy: +- 5%

Capacity accuracy: +-5%

Abnormal protection: reversed, shorted, OLP, OTP, OLP, OCP, OVP

Bluetooth communication: optional function (- BL has Bluetooth )

Size and weight: 240 * 115 * 65mm, 1.2kg

Safety certification: CE, EN62368, EN61000

Here download BM200 user manual and PC application software

BM200-MAN-EN-V2.0.pdf

BM_Client_2S.zip
